Taramps CRX-4 Compact Electronic 4-Way Crossover CRX4 Low Mid High Pass 3 Day De

Details

Number of Ways: 02

Low Via (L+R)

Subsonic Filter: Fixed (Bypass/20/60/80Hz) (-12dB/Oct)

Bass Boost: 2nd order Butterworth

Low Pass Filter: Variable from 0 to 10dB (40 Hz)

High Via L&R

High Pass Filter: 100 Hz to 10 kHz Variable (-12dB/Oct)

Input Impedance: 10K OHMS

Output Impedance: 440 OHMS

Maximum Input level L/R: 4.57V RMS @ (+15.4 dBu

Maximum output level L/R: 9.3V RMS @ (+21.6 dBu)

Maximum output level of the Pass Thru L/R: 9.3V RMS @ (+21.6 dBu)

Frequency Response: (-1dB) de10Hz to 100KHz

Crosstalk (separation between channels): >90dB

Supply Voltage: 10 to 16 VDC

Nominal Consumption: 250mA @ 12.6 Vcc

Protection System:Reverse polarity and short circuit on power input

Dimensions (WxHxD): 140 x 42 x 85mm

Weight: 0.27Kg
